  • Product Description

    TUV 25W - 4P SE UNP/32

    TUV 25W - 4P SE UNP/32

    Order code: 927972204099

    Full Product Code: 871150026440499

    Downloads

    Leaflet
    Size:2.4 MB

    See all downloads

Specifications Show all

General Information
Cap base
4PINSSINGLEENDED  [ 4 Pins Single Ended]
Main application
Disinfection
Useful life (nom.)
9000 h
System description
na  [ -]
Light Technical
Colour Code
-  [ Not Specified]
Colour Designation
-  [ Not Specified]
Depreciation at Useful Lifetime
20 %
Operating and Electrical
Power (Rated) (Nom)
23 W
Lamp current (nom.)
0.35 A
Voltage (Nom)
82 V
Mechanical and Housing
Cap base information
4 Pins Single Ended
UV
UV-C radiation
8.0 W
Product Data
Full product code
871150026440499
Order product name
TUV 25W - 4P SE UNP/32
EAN/UPC – product
8711500264404
Order code
927972204099
Numerator – quantity per pack
1
Numerator – packs per outer box
32
Material no. (12NC)
927972204099
Net weight (piece)
57.000 g
Installation Diagrams
4-Pins Single Ended
4-Pins Single Ended
