    • Product Description

      MASTER MHN-SA 2000W/956 400V XW HO UNP/1
      MASTER MHN-SA 2000W/956 400V XW HO UNP/1
      MASTER MHN-SA

      MASTER MHN-SA 2000W/956 400V XW HO UNP/1

      Downloads

      Leaflet
      Size:373.9 kB

      See all downloads

    Specifications Show all

    Operating and Electrical
    Voltage (Nom)
    205 V
    Voltage (Nom)
    205 V
    Approval and Application
    Energy Consumption kWh/1000 h
    2305 kWh
    Mercury (Hg) Content (Nom)
    215 mg
    Product Data
    Numerator - Quantity Per Pack
    1
    Full product code
    871829124183600
    Material number (12NC)
    928195105129
    Full product name
    MASTER MHN-SA 2000W/956 400V XW HO UNP/1
    Numerator - Packs per outer box
    1
    EAN/UPC - Case
    8718291241836
    Order product name
    MASTER MHN-SA 2000W/956 400V XW HO UNP/1
    Order code
    928195105129
    Controls and Dimming
    Dimmable
    No
    Mechanical and Housing
    Bulb Shape
    TD40  [TD 40mm]
    Bulb Finish
    Clear
    General Information
    Cap-Base
    X830R  [X830R]
    Operating Position
    P15  [Parallel +/-15D or Horizontal(HOR)]
    Light Technical
    Color Code
    956  [CCT of 5600K]
    Color Designation
    Daylight
    Luminous Efficacy (rated) (Nom)
    108 lm/W
    Chromaticity Coordinate Y (Nom)
    366
    Chromaticity Coordinate X (Nom)
    330
    Color rendering index (CRI)
    81
    Correlated Color Temperature (Nom)
    5600 K
    Installation Diagrams
     2000.0 W X830R TD 40mm Clear CCT of 5600K
    2000.0 W X830R TD 40mm Clear CCT of 5600K
    X830R
    X830R
    p15
    p15
    Performance Diagrams
    Lumen Maintenance Diagram - MASTER MHN-SA 2000W/956 400V XW HO UNP/1
    Lumen Maintenance Diagram - MASTER MHN-SA 2000W/956 400V XW HO UNP/1
    Life Expectancy Diagram - MASTER MHN-SA 2000W/956 400V XW HO UNP/1
    Life Expectancy Diagram - MASTER MHN-SA 2000W/956 400V XW HO UNP/1
    Photometrics
    Spectral Power Distribution Colour - MASTER MHN-SA 2000W/956 400V XW HO UNP/1
    Spectral Power Distribution Colour - MASTER MHN-SA 2000W/956 400V XW HO UNP/1
