| Power Factor (Fraction) | 0.9
|
| Inrush time | 221
ms
|
| Cable | -
|
| Line Frequency | 50 or 60
Hz
|
| Number of products on MCB of 16 A type B | 22
|
| Average CLO power consumption | N.A.
W
|
| Connection | Screw connection block 5-pole
|
| Input Frequency | 50 or 60
Hz
|
| Initial CLO power consumption | N.A.
W
|
| Input Voltage | 220 to 240
V
|
| Inrush current | 23.1
A
|
| Ingress protection code | IP20
[Finger-protected] |
| EU RoHS compliant | Yes
|
| Mech. impact protection code | IK03
[0.3 J] |
| Flammability mark | For mounting on normally flammable surfaces
|
| Warranty period | 3 years
|
| ENEC mark | -
|
| CE mark | CE mark
|
| Protection class IEC | Safety class I
|
| Glow-wire test | Temperature 650 °C, duration 30 s
|
| Median useful life L80B50 | 50,000
hour(s)
|
| Median useful life L70B50 | 50,000
hour(s)
|
| Median useful life L90B50 | 33,817
hour(s)
|
| Numerator - Quantity Per Pack | 1
|
| Full product code | 911401548961
|
| Material number (12NC) | 911401548961
|
| Full product name | RC650B LED40S865 PSD W30L120
|
| Numerator - Packs per outer box | 2
|
| Order product name | RC650B LED40S865 PSD W30L120
|
| Order code | 911401548961
|
| Control interface | DALI
|
| Constant light output | No
|
| Driver/power unit/transformer | Power supply unit (ON/OFF)
|
| Dimmable | Yes
|
| Light source engine type | LED
|
| Number of gear units | 1 unit
|
| Driver included | Yes
|
| Reflector material | Polycarbonate
|
| Overall width | 297
mm
|
| Housing Color | White
|
| Optical cover/lens finish | Textured
|
| Optical cover/lens material | Polycarbonate
|
| Dimensions (Height x Width x Depth) | 70 x 297 x 1197 mm
|
| Overall height | 70
mm
|
| Optic material | Polycarbonate
|
| Overall length | 1,197
mm
|
| Housing Material | Steel
|
| Fixation material | Steel
|
| Initial chromaticity | SDCM<3
|
| Power consumption tolerance | +/-10%
|
| Luminous flux tolerance | +/-10%
|
| Maximum dim level | Programmable
|
| Suitable for random switching | No
|
| Ambient temperature range | -20 to +40 °C
|
| Luminaire light beam spread | 100° x 100°
|
| Light source color | 865 cool daylight
|
| Luminous Efficacy (rated) (Nom) | 140.4
lm/W
|
| Optical cover/lens type | Polycarbonate
|
| Luminous Flux | 4,100
lumen
|
| Beam angle of light source | 120
degree(s)
|
| Color rendering index (CRI) | >80
|
| Optic type | Reflector
|
| Correlated Color Temperature (Nom) | 6500
K
|
