    • Philips GreenPerform Waterproof G3: A high-performance, energy-efficient waterproof batten

      WT198X LED38S/865 L1 S PCO L1200
      WT198X LED38S/865 L1 S PCO L1200
      GreenPerform Waterproof G3

      WT198X LED38S/865 L1 S PCO L1200

    Specifications Show all

    Operating and Electrical
    Power Factor (Fraction)
    0.9
    Line Frequency
    50 to 60 Hz
    Number of products on MCB of 16 A type B
    84
    Input Voltage
    220 to 240 V
    Input Frequency
    50 to 60 Hz
    Inrush current
    8 A
    Approval and Application
    Ingress protection code
    IP65  [Dust penetration-protected, jet-proof]
    Mech. impact protection code
    IK08  [5 J vandal-protected]
    Flammability mark
    For mounting on normally flammable surfaces
    CE mark
    CE mark
    Protection class IEC
    Safety class I
    Product Data
    Numerator - Quantity Per Pack
    1
    Material number (12NC)
    911401572791
    Full product name
    WT198X LED38S/865 L1 S PCO L1200
    Numerator - Packs per outer box
    9
    Order product name
    WT198X LED38S/865 L1 S PCO L1200
    Order code
    911401572791
    Controls and Dimming
    Control interface
    -
    Dimmable
    Limited
    General Information
    Light source engine type
    LED
    Mechanical and Housing
    Housing Color
    Gray
    Overall width
    80 mm
    Optical cover/lens finish
    Opal
    Optical cover/lens material
    Polycarbonate
    Dimensions (Height x Width x Depth)
    76 x 80 x 1215 mm
    Housing Material
    Polycarbonate
    Overall height
    76 mm
    Overall length
    1,215 mm
    Initial Performance (IEC Compliant)
    Luminous flux tolerance
    +/-10%
    Initial chromaticity
    5
    Power consumption tolerance
    +/-10%
    Temperature
    Ambient temperature range
    -20 to +45 °C
    Light Technical
    Light source color
    865 cool daylight
    Luminous Efficacy (rated) (Nom)
    139 lm/W
    Optical cover/lens type
    Polycarbonate bowl/cover foggy
    Luminous Flux
    3,800 lumen
    Color rendering index (CRI)
    >80
    Correlated Color Temperature (Nom)
    6500 K
    Installation Diagrams
    Dimension Drawing (without table) - WT198X LED38S/865 L1 S PCO L1200
    Dimension Drawing (without table) - WT198X LED38S/865 L1 S PCO L1200
