    • The new generation of energy-saving tube lighting

      MAS LEDtube VLE DC 1200mm 15.5W 830 T8
      LED
      MAS LEDtube VLE DC 1200mm 15.5W 830 T8
      Other LEDtube

      MAS LEDtube VLE DC 1200mm 15.5W 830 T8

      Downloads

      Leaflet
      Size:933.2 kB

      See all downloads

    Specifications Show all

    Operating and Electrical
    Power Factor (Fraction)
    0.9
    Warm-up time to 60% light
    0.5 s
    Starting Time (Nom)
    0.5 s
    Line Frequency
    50 to 60 Hz
    Voltage (Nom)
    24-34 V
    Input Frequency
    50 to 60 Hz
    Lamp Current (Nom)
    570 mA
    Approval and Application
    EU RoHS compliant
    Yes
    Energy Saving Product
    Yes
    Approval Marks
    RoHS compliance
    Product Data
    Numerator - Quantity Per Pack
    1
    Full product code
    871951446891700
    Material number (12NC)
    929003557121
    Full product name
    MAS LEDtube VLE DC 1200mm 15.5W 830 T8
    Numerator - Packs per outer box
    20
    EAN/UPC - Case
    8719514468924
    Order product name
    MAS LEDtube VLE DC 1200mm 15.5W 830 T8
    Order code
    929003557121
    Controls and Dimming
    Dimmable
    No
    Mechanical and Housing
    Product Length
    1,200 mm
    Bulb Shape
    Tube, double-ended
    Bulb Material
    Glass
    Bulb Finish
    Frosted
    General Information
    Cap-Base
    G13  [Medium Bi-Pin Fluorescent]
    Lighting Technology
    LED
    Nominal lifetime
    50,000 hour(s)
    Switching Cycle
    50,000
    Temperature
    T-Case Maximum (Nom)
    45 °C
    Ambient temperature range
    -20 °C to 45 °C
    Light Technical
    Color Code
    830  [CCT of 3000K]
    Color Designation
    White (WH)
    Beam Angle (Nom)
    240 degree(s)
    LLMF At End Of Nominal Lifetime (Nom)
    70 %
    Color Consistency
    <6
    Luminous Efficacy (rated) (Nom)
    148 lm/W
    Luminous Flux
    2,300 lumen
    Color rendering index (CRI)
    82
    Correlated Color Temperature (Nom)
    3000 K

    Eco passport - Our environmental product specifications overview

    Philips cares about the environment and society at large, and strongly supports eco-design of products.

    Installation Diagrams
     Medium Bi-Pin Fluorescent Tube, double-ended Frosted
    Medium Bi-Pin Fluorescent Tube, double-ended Frosted
    G13
    G13
    Performance Diagrams
    Lumen Maintenance Diagram - MAS LEDtube VLE DC 1200mm 15.5W 830 T8
    Lumen Maintenance Diagram - MAS LEDtube VLE DC 1200mm 15.5W 830 T8
    Lumen Maintenance Diagram - MAS LEDtube VLE DC 1200mm 15.5W 830 T8
    Lumen Maintenance Diagram - MAS LEDtube VLE DC 1200mm 15.5W 830 T8
    Life Expectancy Diagram - MAS LEDtube VLE DC 1200mm 15.5W 830 T8
    Life Expectancy Diagram - MAS LEDtube VLE DC 1200mm 15.5W 830 T8
    Life Expectancy Diagram - MAS LEDtube VLE DC 1200mm 15.5W 830 T8
    Life Expectancy Diagram - MAS LEDtube VLE DC 1200mm 15.5W 830 T8
    Life Expectancy Diagram - MAS LEDtube VLE DC 1200mm 15.5W 830 T8
    Life Expectancy Diagram - MAS LEDtube VLE DC 1200mm 15.5W 830 T8
    Photometrics
    General uniform lighting
    General uniform lighting
    Spectral Power Distribution Colour
    Spectral Power Distribution Colour
    Light Distribution Diagram - MAS LEDtube VLE DC 1200mm 15.5W 830 T8
    Light Distribution Diagram - MAS LEDtube VLE DC 1200mm 15.5W 830 T8
