| Lamp colour code | 830 warm white
|
| Driver included | Yes
|
| Optical cover/lens type | G
[ Glass] |
| Control interface | -
|
| Connection | Flying leads/wires
|
| Cable | Cable 1.0 m without plug 3-pole
|
| Protection class IEC | Safety class I (I)
|
| Flammability mark | NO
[ -] |
| CE mark | -
|
| Input Voltage | 220 to 240
V
|
| Input frequency | 50 or 60
Hz
|
| Inrush current | 1.22
A
|
| Power factor (min.) | 0.9
|
| Dimmable | No
|
| Housing material | Aluminum die–cast
|
| Optical cover/lens material | Tempered glass
|
| Overall length | 133
mm
|
| Overall width | 182
mm
|
| Overall height | 25.5
mm
|
| Effective projected area | 0.017
m²
|
| Colour | Grey
|
| Dimensions (height x width x depth) | 26 x 182 x 133 mm
|
| Ingress protection code | IP65
[ Dust penetration-protected, jet-proof] |
| Mech. impact protection code | IK07
[ 2 J reinforced] |
| Initial luminous flux (system flux) | 3300
lm
|
| Luminous flux tolerance | +/-10%
|
| Initial LED luminaire efficacy | 110
lm/W
|
| Lamp colour temperature | 3000
K
|
| Colour Rendering Index | >80
|
| Initial chromaticity | (0.440, 0.403) SDCM <5
|
| Initial input power | 30
W
|
| Power consumption tolerance | +/-10%
|
| Ambient temperature range | -25 to +40 °C
|
| Full product code | 871951492458199
|
| Order product name | BVP151 LED36/WW PSU 30W SWB G2 KR
|
| EAN/UPC – product | 8719514924581
|
| Order code | 911401843283
|
| SAP numerator – quantity per pack | 1
|
| Numerator – packs per outer box | 16
|
| SAP material | 911401843283
|
| Net Weight (Piece) | 0.730
kg
|
